Forensic Comparison Microscopes
The FS C & FS M Comparison macroscopes are advanced forensic tools designed to precisely examine evidence from bullets, cartridge cases, tool marks, and documents. They offer high-quality optics and motorized functions for accurate and reproducible results.
Features
Apo macro objectives (parfocal and telecentric)
Motorized magnification changer with 10 calibrated steps
Motorized bridge functions (X/Y stage movement, focus drives)
Synchronous X-Y-Z movement
Remote control capability (via Leica SmartMove or Leica STP8000)
Compatible with special object mountings (rotary stages, large object stages, tilting stages, bullet holders, etc.)
Benefits
- Enhanced imaging with universal LED illumination (4500K color temperature), cost effective and long lasting.
- Versatile contrast methods: bright-field, dark-field, DIC, polarization, and fluorescence for any materials application
- Improved ergonomics with adjustable eye tubes and focus knobs enabling user comfort
- Efficient workflow with color-coded diaphragm assistant for ease of use
- Flexible can be configured to your specific needs
- Large sample accommodation (up to 100x100x80 mm)
- Quick sample overview with 0.7x Macro objective (DM2700 M)
- Flexible for both routine and advanced tasks
- Strain-free optics for crystal clear imaging
FS C & FS M
Apo Macro Objectives
Motorized Bridge Functions
